The SOL mini wing ATTAK combines simplicity and safety to operate easily in various modalities as hike&fly, dune soaring, freestyle but also windy flights. Regular practice and ground handling is strictly recommended before speedflying.
The mini wing flying concept is responsive, smooth and stable and attends to skilled and careful pilots with flying experience in dynamic handling to fly fast and in windier conditions when normal paragliders are not recommended.
Project
The ATTAK consists of 26 cells and has internal crossed diagonals applied at the profiles to distribute the weight uniformly. This maintains the canopy very shapely and cleans and reduces the induced drag.
The ATTAK was designed at the new software. Its enhanced design and profile are the result of our continuous development and refinement process in terms of performance paired with stability. The improved features of this project permit a large speed range and excellent stability.
Construction Characteristcs
ATTAK presents:
- Top design;
- Diagonal bands to reduce weight and the number of lines;
- Reinforcements in batten technology;
- Opening on the stabilizers to remove dirt;
- Panels, profiles and parts cut by laser.
Technical Data
| 16 | 18 | 20 | ||
| Zoom | 0,9 | 1 | 1,1 | |
| Cells | 26 | 26 | 26 | |
| Projected Span | 6,40 | 6,70 | 7,10 | m |
| Projected Surface | 13,70 | 15,75 | 17,80 | m2 |
| Projected A/R | 3,01 | 3,01 | 3,01 | |
| Real Wingspan | 8,00 | 8,41 | 8,90 | m |
| Real Surface | 16,00 | 18,00 | 20,00 | m2 |
| Real A/R | 4,00 | 4,00 | 4,00 | |
| Line Diameter | 1,1 - 1,3 - 1,5 - 2,1 | mm | ||
| Height | 463 | 493 | 522 | cm |
| Maximum Profile | 237 | 252 | 268 | cm |
| Minimum Profile | 84 | 90 | 95 | cm |
| Weight | 3,4 | 3,6 | 3,8 | kg |
| Take off Weight Beginner / Intermediate |
<65 <143 |
<80 <176 |
<95 <209 |
kg lbs |
| Take off Weight Intermediate / Advanced |
65-80 |
80-95 |
95-110 |
kg |
| Sink Rate Minimum | 2,2 | 1,8 | 1,4 | m/s |
| Minimum Speed | 29 | 29 | 29 | km/h |
| Trim Speed | 38 | 38 | 38 | km/h |
| Maximum Speed | 52 | 52 | 52 | km/h |
| Glide | 6,5 | 7,0 | 7,5 | |
| Places | 1 | 1 | 1 | |
| Certification | LOAD | LOAD | LOAD | |
The ATTAK incorporates these SOL performance and comfort technologies:
